Paddle2.0案例：人脸关键点检测

时间:2025-07-21 作者:游乐小编

在图像处理中，关键点本质上是一种特征。它是对一个固定区域或者空间物理关系的抽象描述，描述的是一定邻域范围内的组合或上下文关系。它不仅仅是一个点信息，或代表一个位置，更代表着上下文与周围邻域的组合关系。关键点检测的目标就是通过计算机从图像中找出这些点的坐标，作为计算机视觉领域的一个基础任务，关键点的检测对于高级别任务，例如识别和分类具有至关重要的意义。

paddle2.0案例：人脸关键点检测 - 游乐网

关键点检测方法及应用1: 人脸关键点检测

本示例教程当前是基于2.0-rc版本Paddle做的案例实现，未来会随着2.0的系列版本发布进行升级。

1.简要介绍

在图像处理中，关键点本质上是一种特征。它是对一个固定区域或者空间物理关系的抽象描述，描述的是一定邻域范围内的组合或上下文关系。它不仅仅是一个点信息，或代表一个位置，更代表着上下文与周围邻域的组合关系。关键点检测的目标就是通过计算机从图像中找出这些点的坐标，作为计算机视觉领域的一个基础任务，关键点的检测对于高级别任务，例如识别和分类具有至关重要的意义。

关键点检测方法总体上可以分成两个类型，一个种是用坐标回归的方式来解决，另一种是将关键点建模成热力图，通过像素分类任务，回归热力图分布得到关键点位置。这两个方法，都是一种手段或者是途径，解决的问题就是要找出这个点在图像当中的位置与关系。

其中人脸关键点检测是关键点检测方法的一个成功实践，本示例简要介绍如何通过飞桨开源框架，实现人脸关键点检测的功能。这个案例用到的是第一种关键点检测方法——坐标回归。我们将使用到新版的Paddle2.0的API，集成式的训练接口，能够很方便对模型进行训练和预测。

2.环境设置

导入必要的模块，确认自己的飞桨版本。如果是cpu环境，请安装cpu版本的Paddle2.0环境，在 paddle.set_device() 输入对应运行设备。

In [1]

import numpy as npimport matplotlib.pyplot as pltimport pandas as pdimport osimport paddlefrom paddle.io import Datasetfrom paddle.vision.transforms import transformsfrom paddle.vision.models import resnet18from paddle.nn import functional as Fprint(paddle.__version__)# device = paddle.set_device('gpu') device = paddle.set_device('cpu') # if use static graph, do not setpaddle.disable_static(device)

登录后复制

2.0.0-rc0

登录后复制

3.数据集

3.1 数据集下载

本案例使用了Kaggle最新举办的人脸关键点检测challenge数据集，正式：https://www.kaggle.com/c/facial-keypoints-detection

最新数据集将人脸图像和标注数据打包成了csv文件，我们使用panda来读取。其中数据集中的文件：
training.csv: 包含了用于训练的人脸关键点坐标和图像。
test.csv: 包含了用于测试的人脸关键点图像, 没有标注关键点坐标。
IdLookupTable.csv: 测试集关键点的位置的对应名称。

图像的长和宽都为96像素，所需要检测的一共有15个关键点。

In [3]

!unzip -o data/data60/test.zip -d data/data60/!unzip -o data/data60/training.zip -d data/data60

登录后复制

unzip:  cannot find or open data/data60/test.zip, data/data60/test.zip.zip or data/data60/test.zip.ZIP.

登录后复制

3.2 数据集定义

飞桨（PaddlePaddle）数据集加载方案是统一使用Dataset（数据集定义） + DataLoader（多进程数据集加载）。

首先我们先进行数据集的定义，数据集定义主要是实现一个新的Dataset类，继承父类paddle.io.Dataset，并实现父类中以下两个抽象方法，getitem__和__len：

In [4]

Train_Dir = 'data/data60//training.csv'Test_Dir = 'data/data60//test.csv'lookid_dir = 'data/data60/IdLookupTable.csv'class ImgTransforms(object):    """    图像预处理工具，用于将图像进行升维(96, 96) => (96, 96, 3)，    并对图像的维度进行转换从HWC变为CHW    """    def __init__(self, fmt):        self.format = fmt    def __call__(self, img):        if len(img.shape) == 2:            img = np.expand_dims(img, axis=2)        img =  img.transpose(self.format)        if img.shape[0] == 1:            img = np.repeat(img, 3, axis=0)        return imgclass FaceDataset(Dataset):    def __init__(self, data_path, mode='train', val_split=0.2):        self.mode = mode        assert self.mode in ['train', 'val', 'test'], \            "mode should be 'train' or 'test', but got {}".format(self.mode)        self.data_source = pd.read_csv(data_path)        # 清洗数据, 数据集中有很多样本只标注了部分关键点, 这里有两种策略        # 第一种, 将未标注的位置从上一个样本对应的关键点复制过来        # self.data_source.fillna(method = 'ffill',inplace = True)        # 第二种, 将包含有未标注的样本从数据集中移除        self.data_source.dropna(how="any", inplace=True)          self.data_label_all = self.data_source.drop('Image', axis = 1)                # 划分训练集和验证集合        if self.mode in ['train', 'val']:            np.random.seed(43)            data_len = len(self.data_source)            # 随机划分            shuffled_indices = np.random.permutation(data_len)            # 顺序划分            # shuffled_indices = np.arange(data_len)            self.shuffled_indices = shuffled_indices            val_set_size = int(data_len*val_split)            if self.mode == 'val':                val_indices = shuffled_indices[:val_set_size]                self.data_img = self.data_source.reindex().iloc[val_indices]                self.data_label = self.data_label_all.reindex().iloc[val_indices]            elif self.mode == 'train':                train_indices = shuffled_indices[val_set_size:]                self.data_img = self.data_source.reindex().iloc[train_indices]                self.data_label = self.data_label_all.reindex().iloc[train_indices]        elif self.mode == 'test':            self.data_img = self.data_source            self.data_label = self.data_label_all        self.transforms = transforms.Compose([            ImgTransforms((2, 0, 1))        ])    # 每次迭代时返回数据和对应的标签    def __getitem__(self, idx):        img = self.data_img['Image'].iloc[idx].split(' ')        img = ['0' if x == '' else x for x in img]        img = np.array(img, dtype = 'float32').reshape(96, 96)        img = self.transforms(img)        label = np.array(self.data_label.iloc[idx,:],dtype = 'float32')/96        return img, label    # 返回整个数据集的总数    def __len__(self):        return len(self.data_img)# 训练数据集和验证数据集train_dataset = FaceDataset(Train_Dir, mode='train')val_dataset = FaceDataset(Train_Dir, mode='val')# 测试数据集test_dataset = FaceDataset(Test_Dir,  mode='test')

登录后复制

3.3 数据集抽样展示

实现好Dataset数据集后，我们来测试一下数据集是否符合预期，因为Dataset是一个可以被迭代的Class，我们通过for循环从里面读取数据来用matplotlib进行展示。关键点的坐标在数据集中进行了归一化处理，这里乘以图像的大小恢复到原始尺度，并用scatter函数将点画在输出的图像上。

In [6]

def plot_sample(x, y, axis):    img = x.reshape(96, 96)    axis.imshow(img, cmap='gray')    axis.scatter(y[0::2], y[1::2], marker='x', s=10, color='b')fig = plt.figure(figsize=(10, 7))fig.subplots_adjust(    left=0, right=1, bottom=0, top=1, hspace=0.05, wspace=0.05)# 随机取16个样本展示for i in range(16):    axis = fig.add_subplot(4, 4, i+1, xticks=[], yticks=[])    idx = np.random.randint(train_dataset.__len__())    # print(idx)    img, label = train_dataset[idx]    label = label*96    plot_sample(img[0], label, axis)plt.show()

登录后复制

登录后复制登录后复制登录后复制

4.定义模型

这里使用到paddle.vision.models中定义的resnet18网络模型。在ImageNet分类任务中，图像分成1000类，在模型后接一个全连接层，将输出的1000维向量映射成30维，对应15个关键点的横纵坐标。

In [2]

class FaceNet(paddle.nn.Layer):    def __init__(self, num_keypoints, pretrained=False):        super(FaceNet, self).__init__()        self.backbone = resnet18(pretrained)        self.outLayer1 = paddle.nn.Sequential(            paddle.nn.Linear(1000, 512),            paddle.nn.ReLU(),            paddle.nn.Dropout(0.1))        self.outLayer2 = paddle.nn.Linear(512, num_keypoints*2)    def forward(self, inputs):        out = self.backbone(inputs)        out = self.outLayer1(out)        out = self.outLayer2(out)        return out

登录后复制

4.1 模型可视化

调用飞桨提供的summary接口对组建好的模型进行可视化，方便进行模型结构和参数信息的查看和确认。

In [3]

from paddle.static import InputSpecpaddle.disable_static()num_keypoints = 15model = paddle.Model(FaceNet(num_keypoints))# 输入数据大小：batch_size: 3, channel:3, width:96, height:96model.summary((3, 3, 96, 96))

登录后复制

-------------------------------------------------------------------------------   Layer (type)         Input Shape          Output Shape         Param #    ===============================================================================     Conv2D-1         [[3, 3, 96, 96]]     [3, 64, 48, 48]         9,408        BatchNorm2D-1     [[3, 64, 48, 48]]     [3, 64, 48, 48]          256            ReLU-1         [[3, 64, 48, 48]]     [3, 64, 48, 48]           0           MaxPool2D-1      [[3, 64, 48, 48]]     [3, 64, 24, 24]           0            Conv2D-2        [[3, 64, 24, 24]]     [3, 64, 24, 24]        36,864        BatchNorm2D-2     [[3, 64, 24, 24]]     [3, 64, 24, 24]          256            ReLU-2         [[3, 64, 24, 24]]     [3, 64, 24, 24]           0            Conv2D-3        [[3, 64, 24, 24]]     [3, 64, 24, 24]        36,864        BatchNorm2D-3     [[3, 64, 24, 24]]     [3, 64, 24, 24]          256         BasicBlock-1      [[3, 64, 24, 24]]     [3, 64, 24, 24]           0            Conv2D-4        [[3, 64, 24, 24]]     [3, 64, 24, 24]        36,864        BatchNorm2D-4     [[3, 64, 24, 24]]     [3, 64, 24, 24]          256            ReLU-3         [[3, 64, 24, 24]]     [3, 64, 24, 24]           0            Conv2D-5        [[3, 64, 24, 24]]     [3, 64, 24, 24]        36,864        BatchNorm2D-5     [[3, 64, 24, 24]]     [3, 64, 24, 24]          256         BasicBlock-2      [[3, 64, 24, 24]]     [3, 64, 24, 24]           0            Conv2D-7        [[3, 64, 24, 24]]     [3, 128, 12, 12]       73,728        BatchNorm2D-7     [[3, 128, 12, 12]]    [3, 128, 12, 12]         512            ReLU-4         [[3, 128, 12, 12]]    [3, 128, 12, 12]          0            Conv2D-8        [[3, 128, 12, 12]]    [3, 128, 12, 12]       147,456       BatchNorm2D-8     [[3, 128, 12, 12]]    [3, 128, 12, 12]         512           Conv2D-6        [[3, 64, 24, 24]]     [3, 128, 12, 12]        8,192        BatchNorm2D-6     [[3, 128, 12, 12]]    [3, 128, 12, 12]         512         BasicBlock-3      [[3, 64, 24, 24]]     [3, 128, 12, 12]          0            Conv2D-9        [[3, 128, 12, 12]]    [3, 128, 12, 12]       147,456       BatchNorm2D-9     [[3, 128, 12, 12]]    [3, 128, 12, 12]         512            ReLU-5         [[3, 128, 12, 12]]    [3, 128, 12, 12]          0            Conv2D-10       [[3, 128, 12, 12]]    [3, 128, 12, 12]       147,456      BatchNorm2D-10     [[3, 128, 12, 12]]    [3, 128, 12, 12]         512         BasicBlock-4      [[3, 128, 12, 12]]    [3, 128, 12, 12]          0            Conv2D-12       [[3, 128, 12, 12]]     [3, 256, 6, 6]        294,912      BatchNorm2D-12      [[3, 256, 6, 6]]      [3, 256, 6, 6]         1,024           ReLU-6          [[3, 256, 6, 6]]      [3, 256, 6, 6]           0            Conv2D-13        [[3, 256, 6, 6]]      [3, 256, 6, 6]        589,824      BatchNorm2D-13      [[3, 256, 6, 6]]      [3, 256, 6, 6]         1,024          Conv2D-11       [[3, 128, 12, 12]]     [3, 256, 6, 6]        32,768       BatchNorm2D-11      [[3, 256, 6, 6]]      [3, 256, 6, 6]         1,024        BasicBlock-5      [[3, 128, 12, 12]]     [3, 256, 6, 6]           0            Conv2D-14        [[3, 256, 6, 6]]      [3, 256, 6, 6]        589,824      BatchNorm2D-14      [[3, 256, 6, 6]]      [3, 256, 6, 6]         1,024           ReLU-7          [[3, 256, 6, 6]]      [3, 256, 6, 6]           0            Conv2D-15        [[3, 256, 6, 6]]      [3, 256, 6, 6]        589,824      BatchNorm2D-15      [[3, 256, 6, 6]]      [3, 256, 6, 6]         1,024        BasicBlock-6       [[3, 256, 6, 6]]      [3, 256, 6, 6]           0            Conv2D-17        [[3, 256, 6, 6]]      [3, 512, 3, 3]       1,179,648     BatchNorm2D-17      [[3, 512, 3, 3]]      [3, 512, 3, 3]         2,048           ReLU-8          [[3, 512, 3, 3]]      [3, 512, 3, 3]           0            Conv2D-18        [[3, 512, 3, 3]]      [3, 512, 3, 3]       2,359,296     BatchNorm2D-18      [[3, 512, 3, 3]]      [3, 512, 3, 3]         2,048          Conv2D-16        [[3, 256, 6, 6]]      [3, 512, 3, 3]        131,072      BatchNorm2D-16      [[3, 512, 3, 3]]      [3, 512, 3, 3]         2,048        BasicBlock-7       [[3, 256, 6, 6]]      [3, 512, 3, 3]           0            Conv2D-19        [[3, 512, 3, 3]]      [3, 512, 3, 3]       2,359,296     BatchNorm2D-19      [[3, 512, 3, 3]]      [3, 512, 3, 3]         2,048           ReLU-9          [[3, 512, 3, 3]]      [3, 512, 3, 3]           0            Conv2D-20        [[3, 512, 3, 3]]      [3, 512, 3, 3]       2,359,296     BatchNorm2D-20      [[3, 512, 3, 3]]      [3, 512, 3, 3]         2,048        BasicBlock-8       [[3, 512, 3, 3]]      [3, 512, 3, 3]           0       AdaptiveAvgPool2D-1   [[3, 512, 3, 3]]      [3, 512, 1, 1]           0            Linear-1            [[3, 512]]           [3, 1000]           513,000         ResNet-1         [[3, 3, 96, 96]]        [3, 1000]              0            Linear-2           [[3, 1000]]            [3, 512]           512,512          ReLU-10            [[3, 512]]            [3, 512]              0            Dropout-1           [[3, 512]]            [3, 512]              0            Linear-3            [[3, 512]]            [3, 30]            15,390     ===============================================================================Total params: 12,227,014Trainable params: 12,207,814Non-trainable params: 19,200-------------------------------------------------------------------------------Input size (MB): 0.32Forward/backward pass size (MB): 31.52Params size (MB): 46.64Estimated Total Size (MB): 78.48-------------------------------------------------------------------------------

登录后复制

{'total_params': 12227014, 'trainable_params': 12207814}

登录后复制

5. 训练模型

在这个任务是对坐标进行回归，我们使用均方误差（Mean Square error ）损失函数paddle.nn.MSELoss()来做计算，飞桨2.0中，在nn下将损失函数封装成可调用类。我们这里使用paddle.Model相关的API直接进行训练，只需要定义好数据集、网络模型和损失函数即可。

5.1 启动模型训练

使用模型代码进行Model实例生成，使用prepare接口定义优化器、损失函数和评价指标等信息，用于后续训练使用。在所有初步配置完成后，调用fit接口开启训练执行过程，调用fit时只需要将前面定义好的训练数据集、测试数据集、训练轮次（Epoch）和批次大小（batch_size）配置好即可。

In [9]

model = paddle.Model(FaceNet(num_keypoints=15))optim = paddle.optimizer.Adam(learning_rate=1e-3,    parameters=model.parameters())model.prepare(optim, paddle.nn.MSELoss())model.fit(train_dataset, val_dataset, epochs=60, batch_size=256)

登录后复制

Epoch 1/60step 7/7 - loss: 0.2203 - 570ms/stepEval begin...step 2/2 - loss: 0.2003 - 476ms/stepEval samples: 428Epoch 2/60step 7/7 - loss: 0.1293 - 574ms/stepEval begin...step 2/2 - loss: 0.1363 - 454ms/stepEval samples: 428Epoch 3/60step 7/7 - loss: 0.0499 - 799ms/stepEval begin...step 2/2 - loss: 0.0530 - 455ms/stepEval samples: 428Epoch 4/60step 7/7 - loss: 0.0128 - 557ms/stepEval begin...step 2/2 - loss: 0.0124 - 454ms/stepEval samples: 428Epoch 5/60step 7/7 - loss: 0.0079 - 555ms/stepEval begin...step 2/2 - loss: 0.0068 - 474ms/stepEval samples: 428Epoch 6/60step 7/7 - loss: 0.0028 - 573ms/stepEval begin...step 2/2 - loss: 0.0046 - 454ms/stepEval samples: 428Epoch 7/60step 7/7 - loss: 0.0021 - 559ms/stepEval begin...step 2/2 - loss: 0.0046 - 469ms/stepEval samples: 428Epoch 8/60step 7/7 - loss: 0.0020 - 560ms/stepEval begin...step 2/2 - loss: 0.0024 - 461ms/stepEval samples: 428Epoch 9/60step 7/7 - loss: 0.0018 - 561ms/stepEval begin...step 2/2 - loss: 0.0017 - 454ms/stepEval samples: 428Epoch 10/60step 7/7 - loss: 0.0018 - 563ms/stepEval begin...step 2/2 - loss: 0.0014 - 454ms/stepEval samples: 428Epoch 11/60step 7/7 - loss: 0.0018 - 560ms/stepEval begin...step 2/2 - loss: 0.0011 - 454ms/stepEval samples: 428Epoch 12/60step 7/7 - loss: 0.0016 - 554ms/stepEval begin...step 2/2 - loss: 0.0010 - 456ms/stepEval samples: 428Epoch 13/60step 7/7 - loss: 0.0018 - 559ms/stepEval begin...step 2/2 - loss: 9.8745e-04 - 453ms/stepEval samples: 428Epoch 14/60step 7/7 - loss: 0.0019 - 616ms/stepEval begin...step 2/2 - loss: 9.8130e-04 - 478ms/stepEval samples: 428Epoch 15/60step 7/7 - loss: 0.0015 - 553ms/stepEval begin...step 2/2 - loss: 9.7889e-04 - 454ms/stepEval samples: 428Epoch 16/60step 7/7 - loss: 0.0017 - 567ms/stepEval begin...step 2/2 - loss: 9.5601e-04 - 463ms/stepEval samples: 428Epoch 17/60step 7/7 - loss: 0.0017 - 565ms/stepEval begin...step 2/2 - loss: 9.4202e-04 - 462ms/stepEval samples: 428Epoch 18/60step 7/7 - loss: 0.0017 - 559ms/stepEval begin...step 2/2 - loss: 0.0010 - 457ms/stepEval samples: 428Epoch 19/60step 7/7 - loss: 0.0017 - 567ms/stepEval begin...step 2/2 - loss: 9.7536e-04 - 465ms/stepEval samples: 428Epoch 20/60step 7/7 - loss: 0.0015 - 565ms/stepEval begin...step 2/2 - loss: 9.0152e-04 - 468ms/stepEval samples: 428Epoch 21/60step 7/7 - loss: 0.0014 - 570ms/stepEval begin...step 2/2 - loss: 9.0222e-04 - 462ms/stepEval samples: 428Epoch 22/60step 7/7 - loss: 0.0015 - 568ms/stepEval begin...step 2/2 - loss: 7.8668e-04 - 453ms/stepEval samples: 428Epoch 23/60step 7/7 - loss: 0.0013 - 557ms/stepEval begin...step 2/2 - loss: 7.7608e-04 - 456ms/stepEval samples: 428Epoch 24/60step 7/7 - loss: 0.0013 - 555ms/stepEval begin...step 2/2 - loss: 7.8894e-04 - 458ms/stepEval samples: 428Epoch 25/60step 7/7 - loss: 0.0013 - 566ms/stepEval begin...step 2/2 - loss: 7.6504e-04 - 456ms/stepEval samples: 428Epoch 26/60step 7/7 - loss: 0.0012 - 578ms/stepEval begin...step 2/2 - loss: 7.1451e-04 - 452ms/stepEval samples: 428Epoch 27/60step 7/7 - loss: 0.0012 - 572ms/stepEval begin...step 2/2 - loss: 7.3616e-04 - 749ms/stepEval samples: 428Epoch 28/60step 7/7 - loss: 0.0013 - 553ms/stepEval begin...step 2/2 - loss: 7.3413e-04 - 457ms/stepEval samples: 428Epoch 29/60step 7/7 - loss: 0.0011 - 560ms/stepEval begin...step 2/2 - loss: 7.0764e-04 - 457ms/stepEval samples: 428Epoch 30/60step 7/7 - loss: 0.0011 - 560ms/stepEval begin...step 2/2 - loss: 7.2735e-04 - 457ms/stepEval samples: 428Epoch 31/60step 7/7 - loss: 0.0010 - 567ms/stepEval begin...step 2/2 - loss: 7.9266e-04 - 453ms/stepEval samples: 428Epoch 32/60step 7/7 - loss: 0.0012 - 561ms/stepEval begin...step 2/2 - loss: 6.9983e-04 - 458ms/stepEval samples: 428Epoch 33/60step 7/7 - loss: 0.0010 - 568ms/stepEval begin...step 2/2 - loss: 6.7500e-04 - 457ms/stepEval samples: 428Epoch 34/60step 7/7 - loss: 0.0011 - 568ms/stepEval begin...step 2/2 - loss: 6.6316e-04 - 459ms/stepEval samples: 428Epoch 35/60step 7/7 - loss: 0.0011 - 561ms/stepEval begin...step 2/2 - loss: 6.3884e-04 - 467ms/stepEval samples: 428Epoch 36/60step 7/7 - loss: 9.9395e-04 - 559ms/stepEval begin...step 2/2 - loss: 6.0092e-04 - 456ms/stepEval samples: 428Epoch 37/60step 7/7 - loss: 0.0011 - 550ms/stepEval begin...step 2/2 - loss: 5.8750e-04 - 460ms/stepEval samples: 428Epoch 38/60step 7/7 - loss: 9.3226e-04 - 565ms/stepEval begin...step 2/2 - loss: 5.3959e-04 - 462ms/stepEval samples: 428Epoch 39/60step 7/7 - loss: 9.2422e-04 - 562ms/stepEval begin...step 2/2 - loss: 5.2893e-04 - 454ms/stepEval samples: 428Epoch 40/60step 7/7 - loss: 9.9294e-04 - 558ms/stepEval begin...step 2/2 - loss: 5.6088e-04 - 461ms/stepEval samples: 428Epoch 41/60step 7/7 - loss: 9.5442e-04 - 551ms/stepEval begin...step 2/2 - loss: 5.2197e-04 - 454ms/stepEval samples: 428Epoch 42/60step 7/7 - loss: 9.2407e-04 - 572ms/stepEval begin...step 2/2 - loss: 5.5484e-04 - 473ms/stepEval samples: 428Epoch 43/60step 7/7 - loss: 9.3951e-04 - 576ms/stepEval begin...step 2/2 - loss: 5.0847e-04 - 483ms/stepEval samples: 428Epoch 44/60step 7/7 - loss: 9.3463e-04 - 566ms/stepEval begin...step 2/2 - loss: 5.2639e-04 - 457ms/stepEval samples: 428Epoch 45/60step 7/7 - loss: 9.6260e-04 - 863ms/stepEval begin...step 2/2 - loss: 5.2387e-04 - 459ms/stepEval samples: 428Epoch 46/60step 7/7 - loss: 7.9236e-04 - 562ms/stepEval begin...step 2/2 - loss: 5.2232e-04 - 488ms/stepEval samples: 428Epoch 47/60step 7/7 - loss: 8.8867e-04 - 561ms/stepEval begin...step 2/2 - loss: 5.7546e-04 - 472ms/stepEval samples: 428Epoch 48/60step 7/7 - loss: 9.2187e-04 - 563ms/stepEval begin...step 2/2 - loss: 5.1036e-04 - 467ms/stepEval samples: 428Epoch 49/60step 7/7 - loss: 8.4267e-04 - 573ms/stepEval begin...step 2/2 - loss: 5.0897e-04 - 457ms/stepEval samples: 428Epoch 50/60step 7/7 - loss: 8.1840e-04 - 559ms/stepEval begin...step 2/2 - loss: 4.8478e-04 - 460ms/stepEval samples: 428Epoch 51/60step 7/7 - loss: 7.9169e-04 - 564ms/stepEval begin...step 2/2 - loss: 4.9722e-04 - 457ms/stepEval samples: 428Epoch 52/60step 7/7 - loss: 7.4572e-04 - 561ms/stepEval begin...step 2/2 - loss: 4.6681e-04 - 459ms/stepEval samples: 428Epoch 53/60step 7/7 - loss: 7.7328e-04 - 563ms/stepEval begin...step 2/2 - loss: 4.4126e-04 - 468ms/stepEval samples: 428Epoch 54/60step 7/7 - loss: 8.3519e-04 - 565ms/stepEval begin...step 2/2 - loss: 4.5718e-04 - 461ms/stepEval samples: 428Epoch 55/60step 7/7 - loss: 7.3492e-04 - 586ms/stepEval begin...step 2/2 - loss: 4.7409e-04 - 461ms/stepEval samples: 428Epoch 56/60step 7/7 - loss: 7.7133e-04 - 561ms/stepEval begin...step 2/2 - loss: 4.4491e-04 - 462ms/stepEval samples: 428Epoch 57/60step 7/7 - loss: 7.5041e-04 - 561ms/stepEval begin...step 2/2 - loss: 4.4271e-04 - 843ms/stepEval samples: 428Epoch 58/60step 7/7 - loss: 7.5371e-04 - 848ms/stepEval begin...step 2/2 - loss: 4.9145e-04 - 451ms/stepEval samples: 428Epoch 59/60step 7/7 - loss: 7.7562e-04 - 570ms/stepEval begin...step 2/2 - loss: 4.1318e-04 - 456ms/stepEval samples: 428Epoch 60/60step 7/7 - loss: 7.3029e-04 - 858ms/stepEval begin...step 2/2 - loss: 4.2197e-04 - 454ms/stepEval samples: 428

登录后复制

6. 模型预测

为了更好的观察预测结果，我们分别可视化验证集结果与标注点的对比，和在未标注的测试集的预测结果。

6.1 验证集结果可视化

红色的关键点为网络预测的结果，绿色的关键点为标注的groundtrue。

In [10]

result = model.predict(val_dataset, batch_size=1)

登录后复制

Predict begin...step 428/428 [==============================] - 17ms/step         Predict samples: 428

登录后复制 In [28]

def plot_sample(x, y, axis, gt=[]):    img = x.reshape(96, 96)    axis.imshow(img, cmap='gray')    axis.scatter(y[0::2], y[1::2], marker='x', s=10, color='r')    if gt!=[]:        axis.scatter(gt[0::2], gt[1::2], marker='x', s=10, color='lime')fig = plt.figure(figsize=(10, 7))fig.subplots_adjust(    left=0, right=1, bottom=0, top=1, hspace=0.05, wspace=0.05)for i in range(16):    axis = fig.add_subplot(4, 4, i+1, xticks=[], yticks=[])    idx = np.random.randint(val_dataset.__len__())    img, gt_label = val_dataset[idx]    gt_label = gt_label*96    label_pred = result[0][idx].reshape(-1)    label_pred = label_pred*96    plot_sample(img[0], label_pred, axis, gt_label)plt.show()

登录后复制

/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/ipykernel_launcher.py:5: DeprecationWarning: elementwise comparison failed; this will raise an error in the future.  """

登录后复制

登录后复制登录后复制登录后复制

6.2 测试集结果可视化

In [14]

result = model.predict(test_dataset, batch_size=1)

登录后复制

Predict begin...step 1783/1783 [==============================] - 17ms/step         Predict samples: 1783

登录后复制 In [25]

fig = plt.figure(figsize=(10, 7))fig.subplots_adjust(    left=0, right=1, bottom=0, top=1, hspace=0.05, wspace=0.05)for i in range(16):    axis = fig.add_subplot(4, 4, i+1, xticks=[], yticks=[])    idx = np.random.randint(test_dataset.__len__())    img, _ = test_dataset[idx]    label_pred = result[0][idx].reshape(-1)    label_pred = label_pred*96    plot_sample(img[0], label_pred, axis)plt.show()

登录后复制

登录后复制登录后复制登录后复制
